AS42 (15) is a two-component thermally conductive silicone potting compound, mixed in a mass ratio of 1:1, which can be vulcanized at room temperature or under heating conditions. After curing, it forms an elastic thermal conductive insulating colloid. Low viscosity, good fluidity, suitable for filling small gaps. This product maintains stable performance in the temperature range of -40 to 200 ℃ and does not experience peeling due to high and low temperature impacts. The cured material has excellent insulation performance and is suitable for encapsulation applications of power modules, computing processing modules, control boards, and other devices.
■ Thermal conductivity 1.5W/m·K. ■ Low viscosity, good leveling performance. ■ Excellent environmental aging resistance and high and low temperature resistance. ■ Flame retardancy meets UL94-V0. ■ Compliant with RoHS and Reach, halogen-free.
Product Model | AS42(15) |
Color | Grey |
1:1 | |
5000±1000 25℃ |
|
45±5A | |
3~5h Initial Curing Time 24h Complete Curing Time |
|
-40~200℃ | |
1.5W/m·K |
